Ultraviolet Sterilizer 100mA 10W UVC LED Chip 54-72V UVC Cob LED

Brand Name : LEARNEW

Model Number : LN-CVS6UVC-P9- 275

Certification : CE RoHS SGS

Place of Origin : CHINA

MOQ : 1000

Price : Negotiable price

Payment Terms : T/T, L/C, Western Union

Supply Ability : 800,000PCS per month

Delivery Time : 7-12 working days

Packaging Details : Anti-static Blister packing

Color : Deep UV

wavelength : 265-285nm (Sterilization)

Input current : 100mA (max=150mA)

Size : 6.0*6.0MM

LENS : Quartz Glass

Optical power : 80-120mW

Contact Now

Custom uvc light ultraviolet sterilizer 10w 265-285nm uv led chip

Ultraviolet Sterilizer 100mA 10W UVC LED Chip 54-72V UVC Cob LED

Design Advantage:

  • Quartz glass package
  • High radiant flux
  • Narrow Wavelength
  • Inorganic & Nitrogen package
  • Low thermal resistance

Ultraviolet Sterilizer 100mA 10W UVC LED Chip 54-72V UVC Cob LED

models LN-CVS6UVC-P9- 275
Electronic power 7-10W
Peak wavelength

265-285nm(Sterilization)

Radiant power 80-120mW
Working current 100mA(max=150mA)
Working voltage 54-72V
LED Diode size 6.0*6.0MM
Substrate design ALN coppering
Thermal resistance 0.1-0.2C/W
VIEW ANGLE 120°

Ultraviolet Sterilizer 100mA 10W UVC LED Chip 54-72V UVC Cob LED

Ultraviolet Sterilizer 100mA 10W UVC LED Chip 54-72V UVC Cob LED

Ultraviolet Sterilizer 100mA 10W UVC LED Chip 54-72V UVC Cob LED

Q1: Do you supply OEM,ODM service?

A1: YES,absolutely it can be realized.

Q2: All the pictures are real photo?

A2: Yes, the pictures of all products on this page are 100% real shoot by us.

Q3: How can I get a quotation from you?

A3: Please kindly leave us messages about your needs,including products and quantity,our professional team will reply you very soon (mostly within few hours).

Q4: Is there any discount for bulk order?

A4: Yes, if you need bulk order or you want customized products, we can provide wholesale price.

Q5: Do you support drop shipping and how much is the shippping cost?

A5: Yes, we support drop shipping. You should leave the receiver's information when you place the order, then we will send the goods according the address you have left. The shipping cost are based on your order's volume and weight, and it can be calculated.

Q6: How to place an order?

A6: If you want to place an order, Please feel free to send us an inquiry email or contact us by trademanager online, we will reply you within 24hours(working day).
